HAND TAPS METRIC
Made of high quality material Tungsten Steel (SKS)
Long life and consistent "Reliable Thread"
SPECIFICATIONS
| Item | Code No. | Pitch metric (60˚) | Length Overall(A) | Length Thread(B) | Shank diameter(C) |
|---|---|---|---|---|---|
| Nominal diameter: 1.7mm | - | 0.35mm | 36mm | 13mm | 3mm |
| Nominal diameter: 2mm | - | 0.4mm | 40mm | 15mm | 3mm |
| Nominal diameter: 2.3mm | - | 0.4mm | 42mm | 15mm | 3mm |
| Nominal diameter: 2.5mm | - | 0.45mm | 44mm | 16mm | 3mm |
| Nominal diameter: 2.6mm | - | 0.45mm | 44mm | 16mm | 3mm |
| Nominal diameter: 3mm | - | 0.5mm / 0.6mm | 46mm | 18mm | 4mm |
| Nominal diameter: 3.5mm | - | 0.6mm | 48mm | 18mm | 4mm |
| Nominal diameter: 4mm | - | 0.7mm / 0.75mm / 0.5mm | 52mm | 20mm | 5mm |
| Nominal diameter: 4.5mm | - | 0.75mm / 0.5mm | 55mm | 20mm | 5mm |
| Nominal diameter: 5mm | - | 0.8mm / 0.9mm / 0.5mm | 60mm | 22mm | 5.5mm |
| Nominal diameter: 5.5mm | - | 0.9mm | 60mm | 22mm | 5.5mm |
| Nominal diameter: 6mm | - | 1mm / 0.75mm / 0.5mm | 62mm | 24mm | 6mm |
| Nominal diameter: 7mm | - | 1mm / 0.75mm | 65mm | 26mm | 6.2mm |
| Nominal diameter: 8mm | - | 1.25mm / 1mm / 0.75mm | 70mm | 30mm | 6.2mm |
| Nominal diameter: 9mm | - | 1.25mm / 1mm / 0.75mm | 72mm | 30mm | 7mm |
| Nominal diameter: 10mm | - | 1.5mm / 1.25mm / 1mm / 0.75mm | 75mm | 32mm | 7mm |
| Nominal diameter: 11mm | - | 1.5mm / 1.25mm | 80mm | 38mm | 8mm |
| Nominal diameter: 12mm | - | 1.75mm / 1.5mm / 1.25mm / 1mm | 82mm | 38mm | 8.5mm |
| Nominal diameter: 13mm | - | 1.75mm / 1.5mm | 82mm | 38mm | 9.5mm |
| Nominal diameter: 14mm | - | 2mm / 1.5mm / 1.25mm / 1mm | 88mm | 42mm | 10.5mm |
| Nominal diameter: 15mm | - | 2mm | 88mm | 42mm | 10.5mm |
| Nominal diameter: 16mm | - | 2mm / 1.5mm / 1mm | 95mm | 45mm | 12.5mm |
| Nominal diameter: 17mm | - | 2mm | 95mm | 45mm | 13mm |
| Nominal diameter: 18mm | - | 2.5mm / 2mm / 1.5mm | 100mm | 48mm | 14mm |
| Nominal diameter: 19mm | - | 2.5mm | 100mm | 48mm | 14mm |
| Nominal diameter: 20mm | - | 2.5mm / 2mm / 1.5mm | 105mm | 50mm | 15mm |
| Nominal diameter: 22mm | - | 2.5mm / 2mm / 1.5mm | 115mm | 55mm | 17mm |
| Nominal diameter: 24mm | - | 3mm / 2mm / 1.5mm | 120mm | 58mm | 19mm |
| Nominal diameter: 25mm | - | 3mm / 1.5mm | 120mm | 58mm | 19.5mm |
| Nominal diameter: 26mm | - | 3mm / 2mm / 1.5mm | 125mm | 60mm | 19.5mm |
| Nominal diameter: 27mm | - | 3mm / 2mm / 1.5mm | 130mm | 62mm | 20mm |
| Nominal diameter: 28mm | - | 3mm / 2mm / 1.5mm | 130mm | 62mm | 21.5mm |
| Nominal diameter: 30mm | - | 3.5mm / 3mm / 2mm / 1.5mm | 135mm | 65mm | 23mm |
| Nominal diameter: 32mm | - | 3.5mm / 3mm / 2mm / 1.5mm | 135mm | 65mm | 23mm |
| Nominal diameter: 33mm | - | 3.5mm / 3mm / 2mm | 145mm | 70mm | 25mm |
| Nominal diameter: 34mm | - | 3.5mm / 3mm / 2mm | 145mm | 70mm | 26mm |
| Nominal diameter: 35mm | - | 3.5mm | 145mm | 70mm | 26mm |
| Nominal diameter: 36mm | - | 4mm / 3mm / 2mm / 1.5mm | 155mm | 75mm | 28mm |
| Nominal diameter: 38mm | - | 4mm / 3mm / 2mm / 1.5mm | 155mm | 75mm | 29mm |
